Pluto ice blades that are about as tall as the Freedom Tower

Formed by erosion, the features, known as “penitentes,” are bowl-shaped depressions with blade-like spires around the edge that rise several hundreds of feet.

The research, led by John Moores of York University, Toronto, and done in collaboration with scientists at the Johns Hopkins University Applied Physics Laboratory and NASA Goddard Space Flight Center, indicates that these icy features may also exist on other planets where environmental conditions are similar.

The identification of these ridges in Pluto’s informally named Tartarus Dorsa area suggests that the presence of an atmosphere is necessary for the formation of penitentes – which Moores says would explain why they have not previously been seen on other airless icy satellites or dwarf planets. “But exotic differences in the environment give rise to features with very different scales,” he adds. “This test of our terrestrial models for penitentes suggests that we may find these features elsewhere in the solar system, and in other solar systems, where the conditions are right.”

The research team, which also includes York’s Christina Smith, Anthony Toigo of APL and Scott Guzewich of Goddard Space Flight Center, compared its model to ridges on Pluto imaged by NASA’s New Horizons spacecraft in 2015. Pluto’s ridges are much larger – more than 1,600 feet (about 500 meters) tall and separated by two to three miles (about three to five kilometers) – than their Earthly counterparts.

Nature – Penitentes as the origin of the bladed terrain of Tartarus Dorsa on Pluto

“This gargantuan size is predicted by the same theory that explains the formation of these features on Earth,” says Moores. “In fact, we were able to match the size and separation, the direction of the ridges, as well as their age: three pieces of evidence that support our identification of these ridges as penitentes.”

Moores says though Pluto’s environment is very different from Earth’s — it is much colder, the air much thinner, the sun much dimmer and the snow and ice on the surface are made from methane and nitrogen instead of water — the same laws of nature apply. He adds that both NASA and APL were instrumental in the collaboration that led to this new finding; both provided background information on Pluto’s atmosphere using a model similar to what meteorologists use to forecast weather on Earth. This was one of the key ingredients in Moores’ own models of the penitentes, without which this discovery would not have been made.

Abstract

Penitentes are snow and ice features formed by erosion that, on Earth, are characterized by bowl-shaped depressions several tens of centimetres across, whose edges grade into spires up to several metres tall. Penitentes have been suggested as an explanation for anomalous radar data on Europa4, but until now no penitentes have been identified conclusively on planetary bodies other than Earth. Regular ridges with spacings of 3,000 to 5,000 metres and depths of about 500 metres with morphologies that resemble penitentes have been observed by the New Horizons spacecraft in the Tartarus Dorsa region of Pluto (220°–250° E, 0°–20° N). Here we report simulations, based upon a recent model representing conditions on Pluto in which deepening penitentes reproduce both the tri-modal (north–south, east–west and northeast–southwest) orientation and the spacing of the ridges of this bladed terrain. At present, these penitentes deepen by approximately one centimetre per orbital cycle and grow only during periods of relatively high atmospheric pressure, suggesting a formation timescale of several tens of millions of years, consistent with crater ages. This timescale implies that the penitentes formed from initial topographic variations of no more than a few tens of metres, consistent with Pluto’s youngest terrains.

SOURCES – Nature, NASA
