Antiproton attraction measured to be similar to protons

Researchers revealed evidence this week that the attractive force between antiprotons is similar to that between protons — and measured it.

Specifically, the team measured two important parameters: the scattering length and the effective range of interaction between two antiprotons. This gave scientists a fundamental new way to understand the force that holds together the nuclei in antimatter and how this compares to matter.

“This is about the subtle difference in the way matter and antimatter interact with each other,” said Rice physicist Frank Geurts.

Antiprotons carry the opposite electrical charge and spin that protons do. Like all matter and antimatter, both were created at the instant of the Big Bang. Physicists are still trying to understand why they see so few antiparticles in nature even though particles and antiparticles were produced in equal amounts and annihilate each other on contact.

“It could have been that antimatter didn’t have the same attractive force as matter and would have helped explain how these differences, during the initial part of the Big Bang, might have resulted in antimatter not having survived in the shape of stars and planets, as matter did,” Geurts said.

The find was reported in Nature on behalf of the more than 500 scientists, including Geurts, who work on the STAR experiment, part of the Relativistic Heavy Ion Collider (RHIC) at the U.S. Department of Energy’s Brookhaven National Laboratory. Brookhaven’s story on the discovery appears here.

The scattering length is a measurement of how particles deviate as they travel from source to destination; their paths are visible as three-dimensional traces captured by STAR (which is short for Solenoid Tracker at RHIC). The effective range indicates how close particles need to be for their charges to influence each other, like magnets.

Both are measured in femtometers. One femtometer is one-millionth of a nanometer; a nanometer is one-billionth of a meter.

CAPTION Scientists working at Brookhaven National Laboratory, including physicists at Rice University, have announced the first measurements of the attractive force between antiprotons. The discovery gives physicists new ways to look at the forces that bind matter and antimatter. CREDIT Brookhaven National Laboratory

For antiprotons measured at RHIC, the scattering length was roughly 7.41 femtometers, and the effective range was 2.14 femtometers, nearly equivalent to their proton counterparts. Measuring distances that small involves both sophisticated equipment and sophisticated calculations.

“This discovery isn’t a surprise,” said Xin, whose Ph.D. thesis focuses on rather exotic systems called muonic atoms. “We’ve been studying the interaction between nucleons (particles that make up an atom’s nucleus) for decades, and we’ve always thought the forces between antimatter particles are the same as for matter. But this is the first time we’ve been able to quantify it.”

Xin, a student of Geurts, applied methods developed in his thesis to the analysis. The first task was to determine which particles produced in a collision were indeed antiprotons and whether any two were in close enough proximity to influence each other. Then came correlating their momentum from creation to destruction, typically a few nanoseconds.

“All of the data we collected in 2011 is from 500 million events (collisions between two heavy gold ions),” Xin said. “Pretty much every event can contribute.”

Antimatter can be created in small amounts with a collider like RHIC and analyzed. The collider accelerates the nuclei of heavy atoms to nearly the speed of light and smashes them together to produce elemental particles, antiparticles and exotic materials like quarks, muons and plasmas. All of these can be characterized by tools built at Rice and elsewhere as part of STAR.

RHIC smashed gold ions to produce hundreds of millions of particles, which can be detected by the ionization traces they leave in a gas-filled cylinder that surrounds the collision and a “time-of-flight” sensor. The instrument, the construction of which was led by Rice, tells researchers how many nanosecond it takes particles to travel from the point of impact to sensors at the outer boundaries of the collider.
