Lockheed Martin will scale its combat laser technology to a 500 kW-class laser. It will be the most powerful laser Lockheed Martin has produced, topping its 300 kW-class laser power level developed under a contract from the Department of Defense’s Office of the Under Secretary of Defense for Research & Engineering, OUSD (R&E). The 500 kW-class laser, developed under a new contract just awarded by OUSD (R&E), is the second phase of the High Energy Laser Scaling Initiative (HELSI).
The U.S. Army is working through a variety of challenges with directed-energy weapons for air defense, including how to affordably manufacture the high-tech capability and sustain it on the battlefield.
This contract is worth about $221 million for development alone.
A 2019 report by New Mexico’s Galaxy Advanced Engineering suggests that a megawatt range combat laser (1,000 kW) would be needed toi short down an airplane. This would out about 5000 joules per square centimeter. Less powerful lasers, however, might be able to disable specific thin-skinned targets such as an airplane’s sensors, optics, and related devices.
This phase of HELSI aims to increase the laser’s power level while achieving excellent beam quality and optimizing efficiency, size, weight, and volume for the continuous-wave high energy laser sources. Proving this capability will reduce risk for the Department of Defense acquisition and fielding of high-powered laser weapon systems for all six military branches.
Iron Beam Combat Laser
In 2022, US defense contractor Lockheed Martin signed an agreement with the Israeli Rafael weapons manufacturer to join the development of a high-powered laser interception system, dubbed Iron Beam. Israel has a 100 kilowatt Iron Beam combat laser. Iron Beam is expected to be deployed by the Israel Defense Forces (IDF) by 2024.
Terrorist groups in the Gaza Strip can launch rockets for less than US$1,000. The Tamir interceptor used for Iron Dome is said to cost about US$50,000, and a Patriot missile goes up to US$3 million per piece. The cost of one interception with Iron Beam laser would be much cheaper, with some reports suggesting US$2,000.
Limits of Combat Lasers
Iron Beam still faces a series of technological issues that constrain its operational relevance.
1. weather conditions significantly affect its ability to operate. The sensors of Iron Beam are said to work effectively in optimal conditions such as a sunny and cloudless day, but less so in cases of rain and clouds. This questions the choice of relying on a system that could be made suddenly – and quite randomly – inefficient. Israel has a Mediterranean climate. Weather problems would mostly be an issue during the winter season. Southeast Asian countries have ten times more rain which would reduce combat laser use and effectiveness.
2. the range of the interception. Laser energy is absorbed by molecules and aerosols in the atmosphere and eventually loses power. This means that the system, as of today, could only destroy rockets at short range (reportedly less than 10 km).
3. Another major limitation relates to the pace of intervention. The process of generating a laser beam may take only a few seconds but that makes the system slower than Iron Dome and less effective when facing a salvo of rockets.
Israel has successfully tested the new “Iron Beam” laser interception system.
This is the world’s first energy-based weapons system that uses a laser to shoot down incoming UAVs, rockets & mortars at a cost of $3.50 per shot.
